114

Object

Description

Allowed Access

VLANs

This field shows the allowed Access VLANs, it only affects ports configured as

Access ports. Ports in other modes are members of all VLANs specified in the

Allowed VLANs field.

By default, only VLAN 1 is enabled. More VLANs may be created by using a list

syntax where the individual elements are separated by commas. Ranges are

specified with a dash separating the lower and upper bound.

The following example will create VLANs 1, 10, 11, 12, 13, 200, and 300:

1,10-13,200,300

. Spaces are allowed in between the delimiters.

Ethertype for Custome

S-ports

This field specifies the ethertype/TPID (specified in hexadecimal) used for

Custom S-ports. The setting is in force for all ports whose Port Type is set to

S-Custom-Port.
