239

specific value. The allowed range is 0 to 255. A frame that hits this ACE matches

this IPv6 protocol value.

SIP Filter

Specify the source IPv6 filter for this ACE.

Any

: No source IPv6 filter is specified. (Source IPv6 filter is "don't-care".)

Specific

: Source IPv6 filter is set to Network. Specify the source IPv6

address and source IPv6 mask in the SIP Address fields that appear.

SIP Address

When "Specific" is selected for the source IPv6 filter, you can enter a specific

SIPv6 address. The field only supported last 32 bits for IPv6 address.

SIP BitMask

When "Specific" is selected for the source IPv6 filter, you can enter a specific

SIPv6 mask. The field only supported last 32 bits for IPv6 address. Notice the

usage of bitmask, if the binary bit value is "0", it means this bit is "don't-care".

The real matched pattern is [sipv6_address & sipv6_bitmask] (last 32 bits). For

example, if the SIPv6 address is 2001::3 and the SIPv6 bitmask is

0xFFFFFFFE(bit 0 is "don't-care" bit), then SIPv6 address 2001::2 and 2001::3

are applied to this rule.

Hop Limit

Specify the hop limit settings for this ACE.

zero

: IPv6 frames with a hop limit field greater than zero must not be able

to match this entry.

non-zero

: IPv6 frames with a hop limit field greater than zero must be able

to match this entry.

Any

: Any value is allowed ("don't-care”).

ICMP Parameters

Object

Description

ICMP Type Filter

Specify the ICMP filter for this ACE.

Any

: No ICMP filter is specified (ICMP filter status is "don't-care").

Specific

: If you want to filter a specific ICMP filter with this ACE, you can

enter a specific ICMP value. A field for entering an ICMP value appears.

ICMP Type Value

When "Specific" is selected for the ICMP filter, you can enter a specific ICMP

value.

The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP

value.

ICMP Code Filter

Specify the ICMP code filter for this ACE.

Any

: No ICMP code filter is specified (ICMP code filter status is
