313

The Page includes the following fields:

Object

Description

Mode of ARP Inspection

Configuration

Enable the Global ARP Inspection or disable the Global ARP Inspection.

Port Mode Configuration

Specify ARP Inspection is enabled on which ports. Only when both Global

Mode and Port Mode on a given port are enabled, ARP Inspection is enabled

on this given port. Possible modes are:

Enabled

: Enable ARP Inspection operation.

Disabled

: Disable ARP Inspection operation.

If you want to inspect the VLAN configuration, you have to enable the setting

of "Check VLAN". The default setting of "Check VLAN" is disabled. When the

setting of "Check VLAN" is disabled, the log type of ARP Inspection will refer

to the port setting. And the setting of "Check VLAN" is enabled, the log type of

ARP Inspection will refer to the VLAN setting. Possible setting of "Check

VLAN

" are:

Enabled

: Enable check VLAN operation.

Disabled

: Disable check VLAN operation.

Only the Global Mode and Port Mode on a given port are enabled, and the

setting of "Check VLAN" is disabled, the log type of ARP Inspection will refer

to the port setting. There are four log types and possible types are:

None

: Log nothing.

Deny

: Log denied entries.

Permit

: Log permitted entries.

ALL

: Log all entries.

Buttons

: Click to translate all dynamic entries to static entries.

: Click to apply changes

:

Click to undo any changes made locally and revert to previously saved values.
