240
"don't-care").
■ Specific : If you want to filter a specific ICMP code filter with this ACE, you
can enter a specific ICMP code value. A field for entering an ICMP code
value appears.

ICMP Code Value When "Specific" is selected for the ICMP code filter, you can enter a specific
ICMP code value.
The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP
code value.
 TCP/UDP Parameters
Object Description

TCP/UDP Source Filter Specify the TCP/UDP source filter for this ACE.
■ Any : No TCP/UDP source filter is specified (TCP/UDP source filter status
is "don't-care").
■ Specific : If you want to filter a specific TCP/UDP source filter with this
ACE, you can enter a specific TCP/UDP source value. A field for entering a
TCP/UDP source value appears.
■ Range : If you want to filter a specific TCP/UDP source range filter with this
ACE, you can enter a specific TCP/UDP source range value. A field for
entering a TCP/UDP source value appears.

TCP/UDP Source No. When "Specific" is selected for the TCP/UDP source filter, you can enter a
specific TCP/UDP source value. The allowed range is 0 to 65535. A frame that
hits this ACE matches this TCP/UDP source value.

TCP/UDP Source
Range
When "Range" is selected for the TCP/UDP source filter, you can enter a specific
TCP/UDP source range value. The allowed range is 0 to 65535. A frame that hits
this ACE matches this TCP/UDP source value.

TCP/UDP Destination
Filter
Specify the TCP/UDP destination filter for this ACE.
■ Any : No TCP/UDP destination filter is specified (TCP/UDP destination filter
status is "don't-care").
■ Specific : If you want to filter a specific TCP/UDP destination filter with this
ACE, you can enter a specific TCP/UDP destination value. A field for
entering a TCP/UDP destination value appears.
■ Range : If you want to filter a specific range TCP/UDP destination filter with
this ACE, you can enter a specific TCP/UDP destination range value. A
field for entering a TCP/UDP destination value appears.
