7-13
7.3 Adjustment during tool change
7 Commissioning
7.3 Adjustment during tool change 7300 Adjustment during tool change 7- Inbetriebnahme_Justage_bei_Werkzeugwechsel
The adjustment line is automatically tracked to the tip of the tool. The
tracking of the adjustment line is shown on the display.
7.3.1 Prepare for adjustment during tool change
Prepare for adjustment during tool change 7- Inbetriebnahme_Justage_bei_Werkzeugwechsel_vorbereiten
 Transmitter and receiver must be exactly aligned to each other and to
the centre point of the upper tool, as described in the section entitled
"Initial commissioning".
 The supply voltage must be present.
7.3.2 Tool detection
Tool detection 7- Inbetriebnahme_Justage_bei_Werkzeugwechsel_Werkzeugerkennung
All tool shapes are permitted in principle (but please refer to the warn-
ings in the section entitled "Tool shapes", under "Safety").
In TOOL CHANGE operating mode, the PSENvip detects the contour of
the tool and assigns it to a tool class.
INFORMATION
Generally you should not have to mechanically realign the trans-
mitter and receiver during a tool change.
CAUTION!
The manufacturer or operator of the press must ensure safe
selection of the "Adjustment during tool change" operating
mode with appropriate measures.
CAUTION!
The protective equipment must be tested following a tool
change adjustment!
Use the standardised test piece to perform a function test, see
section entitled "Function test of the safety device".
