7-3
7.2 Initial commissioning
7 Commissioning
Fig. 7-1: Adjustment templates (viewed from the magnet side)
You can select either adjustment template to attach to the transmitter or
receiver side.
7.2.1.3 Adjustment directions of transmitter and receiver
Adjustment directions of transmitter and receiver 7- Inbetriebnahme_Erstinbetriebnahme_Verstellrichtungen
The PSENvip transmitter and receiver can be adjusted in three direc-
tions.
Fig. 7-2: Adjustment directions of transmitter and receiver
Magnet
Alignment grid
Magnet
Back gauge with notch
Cross-hair
