9.3 DIAGNOSTICS menu
9 Diagnostics and Troubleshooting
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
9-6
9.3 DIAGNOSTICS menu 9300 DIAGNOSTICS menu 9- Diagnose_Menue_DIAGNOSTICS
The DIAGNOSTICS menu provides Pilz service staff with further infor-
mation to help them identify faults.
 Press the key.
 Using the keys , select the DIAGNOSTICS menu.
 Press the key to open the DIAGNOSTICS menu.
Diagnose_Menue_DIAGNOSTICS_RL_D_P
Fig. 9-2: Diagnostic data on the display
Diagnose_Menue_DIAGNOSTICS_Legende  1: Diagnostic block
 2: Diagnostic data
 3: Data in hex
9.3.1 Diagnostic blocks and diagnostic data
Diagnostic blocks and diagnostic data 9- Diagnose_Menue_DIAGNOSTICS_Diagnosebloecke
The System Data diagnostic block contains the following diagnostic da-
ta:
 Type: The type of PSENvip
 SW Version: The software version of PSENvip
 Device Data: Device data
 Configuration: Overrun
 Tool Data: Tool data
 Error Statistic: Information on the error rate
 Thresholds: Information on the optical system
 Mod Limits: Information on the optical system
 Run Statistic: Information on the optical system
 Adjust Statistic: Information on the optical system
SYSTEM OK OSSD OFF
DIAGNOSTICS
А
В
Б
System Data: A000
Variant:
0058 3601
