4.4 Description of the units
4 Function description
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
4-14
4.4.3.2 Outputs
Outputs 4- Funktion_Geraete_Empfaenger_Ausgang_OSSD
 OSSD1/OSSD2 in accordance with EN 61496-1, type 4
Two safe outputs that signal the status of the protected field:
OSSD = 1: Protected field clear
OSSD = 0: Protected field broken
Funktion_Geraete_Empfaenger_Ausgang_Mute  Mute1/Mute2 in accordance with EN 61496-1, type 4
Two safe outputs that signal the dynamic muting
Mute1/Mute2 = 1: no dynamic muting
Mute1/Mute2 = 0: dynamic muting active
Funktion_Geraete_Empfaenger_Ausgang_Ausgangstest_Info
Funktion_Geraete_Empfaenger_Ausgang_Ausgangstest
Output test
Outputs that are switched on are checked via regular off tests.
 Test pulses for outputs that are switched on: see Technical Details
 Outputs that are switched on are switched off for the duration of the
test pulse.
 The load must not switch off because of the test.
Outputs that are switched off are checked via regular on tests.
 Test pulses for outputs that are switched off: see Technical Details
 Outputs that are switched off are switched on for the duration of the
test pulse.
INFORMATION
The outputs Mute1/Mute2 have another function during the sys-
tem status TEST. They are used for communication with the
safety system. See "Communication with a safety system" in
this section.
INFORMATION
For details of the output behaviour during a press stroke please
refer also to the section entitled "System cycle", in this chapter.
INFORMATION
The outputs OSSD1/OSSD2 and Mute1/Mute2 are checked via
regular output tests.
