4.4 Description of the units
4 Function description
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
4-18
Funktion_Display_Abbildung
Display
Fig. 4-11: Information on the display
The display is divided into 4 segments:
 1: System status
 2: Status of the OSSD
 3: Input and display field
 4: Operating status
Funktion_Display_Systemzustand
Call up tool change operating mode directly
Confirm entry or menu option selection
Key Description
SYSTEM OK OSSD ON
NORMAL OPERATION
А
Г
В
Б
