10-7
10.2 Communication with the safety system
10 System Connections
LD bComEnd
JMPC END
RESTORE:
LD FALSE
ST bAcknowledgeToolChangeA0
ST bAcknowledgeToolTypeA1
ST bAcknowledgeToolTypeA2
LD TRUE
R bStartCom
R bToolValid
END:
END_FUNCTION_BLOCK
