4.4 Description of the units
4 Function description
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
4-16
4.4.3.3 LED
LED 4- Funktion_Geraete_Empfaenger_LED_OSSD
 OSSD
The OSSD LED on the receiver indicates the status of the protected
field.
Green: The protected field is clear
Red: Protected field is interrupted
Funktion_Geraete_Empfaenger_LED_RL_D_Abbildung
Fig. 4-9: LED on receiver
 1: OSSD LED
1
