Symbols
Documentation symbols
WARNING The warning statements in this manual identify conditions or practices
that could lead to illness, injury, or death.
Caution The caution statements in this manual identify conditions or practices that
could result in damage to the equipment or other property, or loss of data. This
definition applies to both yellow and black and white symbols.
Consult operating instructions.
Power symbols
Power on/standby
Equipotential terminal
(on the display) monitor is
plugged into Alternating
Current power
Battery absent or faulty
(on the monitor, green
indicator) Alternating Current
power present, battery fully
charged
Battery charge level
(on the monitor, amber
indicator) Alternating Current
power present, battery is
charging
Battery cover
Alternating Current (AC)
Rechargeable battery
Li-ion battery
AC input power
