Monitor radio
The monitor's radio operates on Welch Allyn FlexNet™ or other 802.11 networks.
Wireless network interface
IEEE 802.11 b/g, 802.11a
Frequency
802.11 b/g: 2.402 GHz to 2.4835 GHz
802.11a: 5.125 GHz to 5.875 GHz
Channels
Up to 14 in 802.11b/g, up to 24 in 802.11a; country-dependent
Security/encryption/
authentication
WPA2/AES (either EAP or PSK authentication)
Antenna
Internal multiband PIFA
Wireless data rates
802.11b: 1Mbps or higher during vitals transmission only
802.11a/g: 6Mbps or higher during vitals transmission only
(approximately 2 seconds per reading)
Agency approvals
US: FCC Part 15, Class B; C/UL; CE; 47 CFR Part 2.1093, 15.207, 15.209,
15.247, 15.407; FCC OET Bulletin 65C
Europe: CE; EN 50371; EN/ETSI 300 328 V1.7.1, 301 489-1 V1.6.1, 301
489-17 V1.2.1, 301 893 V1.4.1
Canada: RSS-210; RSS-GEN; RSS-102
Hong Kong: HKTA 1039
Protocols
UDP, DHCP, TCP/IP
Data transfer protocols
UDP/TCP/IP
Modulation
OFDM (802.11a/g), DSSS/CCK (802.11b)
Output power
40mW typical, country-dependent
Ancillary IEEE standards
802.11e, 802.11h, 802.11i, 802.11X
Channel restrictions in the 5-GHz band are determined by country.
Marking by the symbol ( ! ) indicates that usage restrictions apply. To ensure compliance with local
regulations, be sure the correct country in which the access point is installed is selected. This
product can be used with the following restriction(s):
France - Outdoor use is limited to 10 mW EIRP within the band 2454 to 2483.5 MHz.
Note
Effective Isotropic Radiated Power (EIRP).
Note
Some countries restrict the use of 5-GHz bands. The 802.11a radio in the monitor
uses only the channels indicated by the access point with which the radio
associates. The hospital IT department must configure access points to operate
with approved domains.
