Network

View advanced monitor information

The Status tab shows the monitor's software version, MAC and IP addresses, network, server and

access point information, session information, and more.

1. Access the Advanced Settings.

a. Touch the Settings tab.
b. Touch the Advanced tab.
c. Enter the Advanced settings code.
d. Touch OK.
The General tab appears.

2. Touch the Network tab.
3. Touch the Status tab.
4. View the information.
5. Do one of the following:

To continue in the Advanced Settings, touch another tab.

To exit the Advanced Settings and return to the Home tab, touch Exit.

Specify radio settings

This task is applicable only to monitors that have a radio installed.

1. Access the Advanced Settings.

a. Touch the Settings tab.
b. Touch the Advanced tab.
c. Enter the Advanced settings code.
d. Touch OK.
The General tab appears.

2. Touch the Network tab.
3. Touch the Radio tab.
4. Specify settings.

Setting

Action/Description

Enable radio

Enable the radio for device communications. When

disabled, the radio is not available.

Enable radio network alarms

Activate radio network alarms when an alarm

condition occurs. When disabled, radio network

alarms are not available.

SSID

Touch

and enter the service set identifier

(SSID). Enter a maximum of 16 characters.

Radio band

Select the radio band.

Authentication type

Select an authentication scheme. Then specify any

additional settings that appear.

134 Advanced settings
