Configuration options
The wall system is available in the following configurations.
Model
Prefix
Description
84 series
Standard. Includes nurse call, Ethernet, and USB connectivity.
85 series
Wireless. Includes all Standard features plus an internal 802.11 a/b/g radio.
Patents
The monitor is covered under the following patents:
6,000,846; 6,036,361; 7,255,475; 7,429,245; D480,977; D632,397; and other patents pending.
For SureTemp Plus configured monitors, US patent 6,971,790 applies.
For Nellcor-equipped monitors, the following Nellcor US patents and foreign equivalents apply:
5,485,847; 5,676,141; 5,743,263; 6,035,223; 6,226,539; 6,411,833; 6,463,310; 6,591,123; 6,708,049;
7,016,715; 7,039,538; 7,120,479; 7,120,480; 7,142,142; 7,162,288; 7,190,985; 7,194,293; 7,209,774;
7,212,847; 7,400,919.
For Masimo-equipped monitors, the following Masimo US patents and foreign equivalents apply:
5,758,644; 5,823,950; 6,011,986; 6,157,850; 6,263,222; 6,501,975; 7,469,157; and others listed at
www.masimo.com/patents.htm.
