Method
Select a method. Then touch
and enter
characters:
Network key
(64 characters), or
Passphrase
(8 to 63 characters).
Security protocol
Select the security protocol.
EAP type
Select the EAP type.
Identity
Enter the EAP identity (maximum of 32 characters).
Password
Enter the EAP password (maximum of 32
characters).
Key number
Select the WEP key number.
Key
Enter the WEP key (10 characters for WEP 64, or 26
characters for WEP 128).
Configure radio
Touch
Configure radio
to activate all new
radio settings not selected previously.
Touch
OK
in the confirmation popup telling you to
power down the monitor.
Touch the
Settings
tab. Touch the
Device
tab.
Touch
Power down
.
The radio will reboot.
Note If you do not touch
Configure radio
,
none of the changed radio settings will take effect.
5. Do one of the following:
•
To continue in the Advanced Settings, touch another tab.
•
To exit the Advanced Settings and return to the Home tab, touch Exit.
Specify server settings
1. Access the Advanced Settings.
a. Touch the Settings tab.
b. Touch the Advanced tab.
c. Enter the Advanced settings code.
d. Touch OK.
The General tab appears.
2. Touch the Network tab.
3. Touch the Server tab.
4. Specify settings.
Setting
Action/Description
Obtain server IP information automatically
Enable the monitor to automatically obtain the
server IP information via the network.
UDP broadcast port
: Touch
and enter
the port number that is used to automatically obtain
server IP information. The range of entry is 0 to
65535.
