Message
Possible cause
Suggested action
Replace the SpO2 sensor.
The SpO2 sensor is faulty or expired
Replace the SpO2 sensor.
No SpO2 sensor is connected
Connect an SpO2 sensor.
The cable is faulty or expired
Replace the cable.
Replace the SpO2 cable.
The cable is faulty or expired
Replace the cable.
Low SpO2 signal quality. Check
sensor.
Poor sensor placement on the patient
Remove the sensor from the
patient and reapply.
Low SpHb signal quality. Check
sensor.
Poor sensor placement on the patient
Remove the sensor from the
patient and reapply.
Low perfusion. Check sensor.
Poor sensor placement on the patient
Remove the sensor from the
patient and reapply.
SpO2 mode only. Check sensor
or cable.
The sensor is operating as an SpO2-only
sensor because it failed to calibrate properly
Reattach the cable to the
monitor.
Remove the sensor from the
patient and reapply.
SpO2 sensor expires in….
The SpO2 sensor will expire soon
Replace the SpO2 sensor.
Temperature messages
Message
Possible cause
Suggested action
Connect temperature probe.
No probe is connected
Connect a temperature probe
and retry.
The probe is faulty
Replace the temperature
probe.
The temperature module
returned a connect probe
message
Connect a temperature probe
and retry. If a probe is already
connected, replace the probe.
Insert correct color-coded probe well.
The probe well is missing
Insert a temperature probe
well.
Replace temperature probe.
The probe is faulty
Replace the temperature
probe.
Temperature not functional. Call for service. A module error occurred
Call for service.
Temperature time limit exceeded.
The 10-minute timeout for
temperature measurement has
occurred
Remove the probe from the
measurement site.
Tissue contact lost
The probe has lost contact
with the patient's tissue
Reposition the probe to restore
proper contact with the
patient's tissue.
