Power data tab – Rockwell Automation Motion Analyzer Software User Manual
Page 57
Rockwell Automation Publication MOTION-UM004B-EN-P - October 2012
57
Welcome to Motion Analyzer Software
Chapter 1
Table 36 -
Power Supply/Accessories (refer to
1.2.2.4.4.2.1. Power Data Tab
Use the Power Data tab to view regeneration and motoring data for each axis.
Figure 44 - Power Data Tab
Table 37 - Power Data Tab Properties (refer to
Parameters
Description
View regeneration and motoring data for each axis.
Select the shunt and capacitor for your system.
Analyze the drive module activity in terms of bus voltage and system current. With this
tab, you can also simulate changes to the system parameters.
View input current values and energy savings estimates for each axis.
Configure Power Supply BOM
Tab
Configure the bill of materials (BOM) for the power supply after fully sizing the
application.
Parameters
Description
Axis histograms
The axis histograms show a multi-axis representation of axis currents including peak motoring,
average motoring, peak regenerating, and average regenerating.
