How to Use This Manual 2-1
C
HAPTER
2
How to Use This Manual
This manual provides configuration guidance for users of the OIM and the WebPakCS
Configuration Software.
2.1 If You Are Using WebPakCS Software to Configure
the Drive
The chapter titles in this manual correspond to the screen selections available in the
WebPakCS software. Each chapter guides you through the parameters as they
appear on the screens.
2.2 If You Are Using the OIM to Configure the Drive
Use table 2.1 to locate the appropriate chapters in this manual for your application.
Each chapter guides you through the parameters you need to configure.
If you are unsure of which application type to select, read Appendix A in this manual
before proceeding.
Refer to Appendix A in the drive software manual (D2-3444) for block diagrams.
Record parameter values in this book and then transfer the values to Appendix B of
the software manual (D2-3444). This will enable you to verify that all the appropriate
parameters have been set.
Then configure the drive using the values you entered in Appendix B. Appendix B
provides the OIM menu path for each parameter.
Table 2.1 – Locating the Appropriate Chapters for Your Application
For This Application: Use These Chapters:
Constant Diameter Speed Regulator 1, 2, 3, 4, 5, 8, 13
Variable Diameter Speed Regulator 1, 2, 3, 4, 5, 6, 7, 8, 13
Constant Diameter Current Regulator 1, 2, 3, 4, 5, 8, 9 (9.1), 10, 13
Variable Diameter Current Regulator 1, 2, 3, 4, 5, 6, 7, 8, 9 (9.1), 10, 13
Constant Diameter Position Regulator 1, 2, 3, 4, 5, 9, 11, 13
Variable Diameter Position Regulator 1, 2, 3, 4, 5, 6, 7, 8, 9, 11, 13
Constant Diameter Tension Regulator 1, 2, 3, 4, 5, 8, 9 (9.1), 12, 13
Variable Diameter Tension Regulator 1, 2, 3, 4, 5, 6, 7, 8, 9 (9.1), 12, 13
Generic All
