Getting Started

1-1

C

HAPTER

1

Getting Started

This manual provides guidance in configuring the WebPak

3000 DC drive for

web-handling applications.

What You Need to Know

You must be qualified to program the drive and be familiar with web-handling
applications. If you are unfamiliar with web-handling applications, read Appendix A
in this manual before proceeding.

You should be familiar with the WebPak Operator Interface Module (OIM) or the
WebPakCS

Configuration Software.

What You Need to Do

Complete all hardware installation as described in the WebPak 3000 drive hardware
reference manual (D2-3443).

Perform Quick Start as described in the OIM manual or configure the initialization
parameters using the WebPakCS software.

Note that no entry fields will be provided in this Workbook for Quick Start
parameters. Record these values in Appendix B of the software manual (D2-3444)
during the Quick Start procedure.

Self-tune the current minor loop and the speed loop as described in the OIM
manual.

Determine your application type and locate the appropriate chapters in this manual
according to table 2.1 in chapter 2.

1.1

Where to Find Additional Information

To find information on:

Hardware, including installation, wiring, and troubleshooting information: See
D2-3443, WebPak 3000 DC Drive Hardware Reference.

Software, including parameter descriptions and block diagrams: See D2-3444,
WebPak 3000 DC Drive Software Reference.

The Operator Interface Module (OIM), including setting parameters, saving
parameters, and using Quick Start: See D2-3445, WebPak 3000 Drive Operator
Interface Module (OIM) User Guide.

Configuration Software: See D2-3447, WebPakCS Configuration Software.

!

ATTENTION: WebPak 3000 DC drive parameters must be configured by
a qualified person who understands the significance of configuring them
accurately. Failure to observe this precaution could result in severe bodily
injury or loss of life.
