Configuring the Speed Loop

3-3

Set

LINE

SPEED

ZERO

ADJ

(P.102

) to

adjust the zero point of the

line speed reference input to remove any offset from the input
signal

.

Set

TOP

LINE

SPEED

(P.020).

LINE

SPEED

(P.188) is the analog output of the line speed reference

after it has been scaled by the hardware and software.

þ

If

LINE

SPEED

REF

SELECT

(P.103) =

FREQUENCY

IN

:

Verify that a frequency section speed reference is connected to
terminals 39 (A), 40 (A Not), and 41 (common) on the I/O
Expansion board.

Set

FREQ

IN

FULL

SCALE

(P.424).

Set

FREQ

IN

ZERO

(P.423)

.

The selected value of the speed loop reference is displayed in

SPD

SOURCE

SELECT

OUT

(P.193) in user-defined units.

þ

If the

CONTROL

SOURCE

(P.000) =

NETWORK

:

Refer to the appropriate network manual for instructions on setting up
the network parameters.

3.1.1 Configuring Trim (Optional)

If the drive is to be configured as a speed follower section, the speed loop reference
function includes a trim reference capability. Trim is based on the signal from the
source selected in

TRIM

REFERENCE

SELECT

(P.108). It is summed with the speed loop

reference before being acted upon by the reference ramping function.

Refer to figure A.4 in the software manual (D2-3444) as you configure trim.

þ

To configure trim:

Set

TRIM

REFERENCE

SELECT

(P.108) to specify the trim reference source. The

choices are:

REGISTER

- The trim reference signal is based on the value set in

TRIM

REF

REGISTER

(P.107).

ANALOG

- The trim reference signal is based on the analog input

(diameter/input range) at terminals 17(+), 18(-), and 16(10V) on the Regulator
board.

Range: -200 to 200

COUNTS

P.102 =

COUNTS

!

ATTENTION: Do not allow the motor to exceed the maximum safe speed
of the motor or driven equipment as determined by the equipment
manufacturer. Failure to observe this precaution could result in bodily
injury.

Range: 0 to 5000

FPM

P.020 =

FPM

Range: 2.0 to 250.0 kHz

P.424 =

K

H

Z

Range: 2.0 to P.424

P.423 =

K

H

Z
