Configuring the Position Outer Loop

11-5

The output of the

SCALE

block is

TEN

/

DANCER

FDBK

SCALED

(P.489). See the following

examples for more information on setting up the

SCALE

block.

11.3 The Position PI Output

Refer to figure A.16 in appendix A of the software manual (D2-3444) as you configure
the position

PI

output.

The output of the

PI

block is

POSITION

VERNIER

(P.241), which is used as a trim signal

on the speed loop when

CASCADE

is selected, or as the input to the speed loop limits

when

PARALLEL

is selected as configured by

OCL

TYPE

(P.818).

The amount of speed loop trim is set by the

HI

and

LO

limits of the

PI

block, which

would nominally be configured at 10% by setting

POS

PI

LIMIT

(P.235) to 409.5.

However, product characteristics, such as modulus of elasticity, can require more or
less than 10% trim.

Note that

POSITION

VERNIER

(P.241) will be a proportional or incremental trim of line

speed, dependent on the configuration of

OCL

PROP

TRIM

GAIN

(P.812). Refer to section

3.3, Speed Mode Select.

þ

To configure the position

PI

output:

Set

POS

PI

LIMIT

(P.235) to set the

HI

and

LO

output limits of the

PI

block.

Setting Up the Scale Block

The setting for

TENSION

FDBK

MIN

(P.852) and

TENSION

FDBK

MAX

(P.851) depend on

the characteristics of the dancer feedback signal.

The output of the

SCALE

block will go from 0 to 4095 counts as the dancer goes

from zero storage to maximum storage. Typically, the dancer feedback signal will be
zero at zero storage and maximum at maximum storage.

Example 1

If the dancer feedback signal can be set, by external calibration and/or analog input
calibration, so that

TENSION

/

DANCER

FDBK

(P.493) is 0 to 10 volts as the dancer

moves from minimum to maximum position, then

TENSION

FDBK

MIN

(P.852) would

be set to 0, and

TENSION

FDBK

MAX

(P.851) would be set to 4095.

Example 2

The dancer feedback signal (analog input) goes from 1.0 volts to 8.0 volts as the
dancer moves from minimum to maximum position, and

TENSION

/

DANCER

FDBK

(P.493), which is the digitized equivalent, goes from 409 to 3276. In this example,

TENSION

FDBK

MIN

(P.852) would be set to 409 and

TENSION

FDBK

MAX

(P.851) would

be set to 3276.

Range: 0 to 4095

COUNTS

(4095 =

TOP

LINE

SPEED

)

P.235 =

COUNTS
