3-10

WebPak 3000 DC Drive Application Workbook, Version 1.1

Selecting the outer loop type

Refer to figure A.6 in Appendix A of the software manual (D2-3444).

3.3.1 Configuring Jog

Two of the three parameters used to configure jog were set during Quick Start:

JOG

SPEED

(P.012) specifies the speed level for jogging in either the forward or reverse

direction. This value is the input to a

RATELIM

block. The output of the

RATELIM

block is

defined as

JOG

RAMP

OUTPUT

(P.294).

JOG

ACCEL

/

DECEL

TIME

(P.013) sets a common acceleration and deceleration time.

þ

To configure jog:

Set

JOG

OFF

DELAY

TIME

(P.121) to specify the minimum delay between

removing the jog reference to the drive and the opening of the main contactor.
This delay reduces contactor wear if the drive is jogged repeatedly for a short
period of time.

3.3.2 Selecting the Outer Loop

þ

To select the outer control loop:

Set

OCL

SELECT

(P.817) to select which outer control loop will be configured.

The choices are:

NONE

- Sets the drive as a speed regulator.

TENSION

,

CURRENT

, or

POSITION

- Operates with the speed loop in either a

CASCADE

or

PARALLEL

configuration as selected by

OCL

TYPE

(P.818). Set

OCL

SELECT

(P.817) to

POSITION

when

OCL

TYPE

3

POSN

REG

(P.814) is set to

ENABLED

.

!

ATTENTION: This drive can operate at and maintain zero speed when

JOG

SPEED

(P.012) is set to zero. A voltage-regulated drive can produce

zero speed at low minimum speed values. The user is responsible for
assuring safe conditions for operating personnel by providing suitable
guards, audible or visual alarms, or other devices to indicate that the
drive is operating at or near zero speed. Failure to observe this precaution
could result in severe bodily injury or loss of life.

Range: 0 to 10

SECONDS

P.121 =

SECONDS

Range:

NONE

,

TENSION

,

CURRENT

,

POSITION

P.817 =

!

ATTENTION: The user must read and understand the drive sequencing
description and state diagram (figure 3.3 in the software manual,
D2-3444) before using the

TENSION

ON

input. Setting

OCL

SELEC

t to any

value but

NONE

permits the

TENSION

ON

input to start the drive. Once the

TENSION

ON

input is permitted to start the drive, negating the

TENSION

ON

input while in any state other than the stall tension state will not stop the
drive. Failure to observe this precaution could result in severe bodily
injury or loss of life.
