7-2

WebPak 3000 DC Drive Application Workbook, Version 1.1

JBAR

= time to accelerate an empty core to base speed with full shunt field

excitation. The results of speed loop self tuning should yield a value for

JBAR

in

SYSTEM

INERTIA

(P.222) or it can be calculated as:

JBAR

(seconds) = Total Inertia (lb-ft

2

) X Motor Base Speed (RPM)

308 X Motor Full Load Torque (lb-ft)

DI

= the diameter of the roll used to calculate

JBARI

D

EC

= empty core diameter

DBARI

= normalized instantaneous diameter =

D

I

/

Dec

W

I

= width of product on roll when

JBARI

is measured

W

MAX

= maximum product width

WDBARI

= normalized product width =

W

I

/

W

MAX

Set

WIDTH

/

BUILDUP

FACTOR

(P.872), which is configured as a ratio of maximum

material width. The parameter is normalized so that maximum width = 1.000.
P.872 can be arbitrarily set to provide additional accuracy for

BUILDUP

CONSTANT

(P.871).

For example: If the buildup constant resulted in a value of 0.00154, change
the buildup constant to 0.154 and assume a value of 0.01 for P.872. Then:

0.01 x 0.154 = 0.00154 (the desired value of P.871)

7.2

Inertia-to-Current Scaling

The output of the inertia-to-current scaling function block is multiplied by

NORM

FIELD

REF

(P.130). This sets the motor armature current required to accelerate the calculated

inertia at the desired rate, and is defined as output parameter

INERTIA

COMPENSATION

(P.244). Refer to figure A.15 in Appendix A of the software manual (D2-3444).

Three of the inputs to the inertia-to-current scaling function block are calculated by the
system:

INSTANTANEOUS

INERTIA

(P.230) which is the output of the instantaneous system

inertia function block (refer to figure A.14 in Appendix A of the software manual,
D2-3444).

The output of a multiply block which uses inputs from

BASE

SPEED

(P.017) and

NORM

ROLL

DIAMETER

(P.131) to calibrate to rotational speed.

REFERENCE

RATE

(P.866), which is the line speed rate of change. The maximum

value is 4095 when

TOP

LINE

SPEED

(P.020) is reached in 1 second.

The remaining inputs are user-configurable.

þ

To set up the inertia-to-current scaling block:

Set

SYSTEM

INERTIA

(P.222), which is the value of

JBAR

as defined in section

7.1.

Range: 0.000 to 1.000

P.871 =

Range: 0.001 to 1.000

P.872 =

Range: 0.05 to 65.20

SECONDS

P.222 =

SECONDS
