Configuring the Outer Control Loop Reference

9-3

9.1.2 The Taper Function

þ

To implement a taper function for winder tension profiling with roll buildup:

The section run input and the tension on input must be asserted.

Set

TAPER

ENABLE

(P.858) to

ENABLE

. This will modify the tension reference

based on the dynamic value of

TAPER

PERCENT

(P.859) which is the product of

TAPER

SET

SELECT

(P.862) and

TAPER

TYPE

(P.863). (See section 9.1.3, Taper

Type.)

Set

TAPER

SET

SELECT

(P.862) to configure the source of the value used to

calculate the percent reduction of the tension reference from core to full roll
winder diameters. The choices are:

REGISTER

- Provides a taper percentage based on the value of

TAPER

SET

REGISTER

(P.861).

ANALOG

- Provides a taper percentage based on the value of the dual function

diameter/taper range analog input signal at terminals 16, 17, and 18 on the
Regulator board.

þ

If

TAPER

SET

SELECT

(P.862) =

REGISTER

:

Set

TAPER

SET

REGISTER

(P.861).

þ

If

TAPER

SET

SELECT

(P.862) =

ANALOG

:

Set

DIAMETER

/

TAPER

SELECT

(P.870) to

TAPER

RANGE

to configure the

analog input function.

Set

DIAMETER

/

TAPER

ZERO

(P.105) to adjust the zero point of the

diameter/taper range input (terminals 16, 17, and 18 on the Regulator
board).

Set

DIAMETER

/

TAPER

GAIN

(P.104) to adjust the gain for the

diameter/taper range input.

DIAMETER

/

TAPER

IN

TP

(P.192) is the digital value of the analog input.

9.1.3 The Taper Type

þ

To configure the taper type:

Set

TAPER

TYPE

(P.863) to select the diameter-sensitive curve that the taper

signal will follow. The choices are:

LINEAR

- Provides a linear change in tension, decreasing from core to full roll

as determined by the output of the diameter calculator

NORM

ROLL

DIAMETER

(P.131).

Range:

ENABLE

,

DISABLE

P.858 =

(1$%/(

Range:

REGISTER

,

ANALOG

P.862 =

Range: 0.0 to 100.0%

P.861 =

%

Range:

DIAMETER

,

TAPER

RANGE

P.870 =

7$3(5 5$1*(

Range: -3000 to 3000

P.105 =

Range: 0.750 to 2.250

P.104 =
