4-2

WebPak 3000 DC Drive Application Workbook, Version 1.1

The composite

CML

reference signal, read as

CML

RAMP

INPUT

TP

(P.390), passes

through an amplitude limit block and a rate limit block. The amplitude limit block
prevents the reference signal from becoming greater than or less than the limits
selected by

CML

REF

LIMIT

SELECT

(P.311). The rate limit block limits the rate of change

of the selected

CML

reference based on the value you input for

CML

REF

RATE

LIMIT

(P.303).

The amplitude- and rate-limited

CML

reference appears as the output parameter

CML

REFERENCE

(P.396).

þ

To configure the current minor loop reference:

Set

INERTIA

COMP

SELECT

(P.221) to select the source of the inertia

compensation signal. The choices are:

NONE

- No inertia compensation signal is added to the current minor loop

reference.

CALCULATOR

- The drive uses the output of the inertia compensation calculator

(

INERTIA

COMPENSATION

(P.244)).

NETW

IN

REG

1, 2, 3 - The drive uses a network value.

Set

LOSSES

COMP

SELECT

(P.315) to select the source of the losses

compensation signal. The choices are:

NONE

- No losses compensation signal is added to the current minor loop

reference.

CALCULATOR

- The drive uses the output of the losses compensation calculator

(

LOSSES

COMPENSATION

(P.316)).

NETW

IN

REG

1, 2, 3 - The drive uses a network value.

Set

OCL

TYPE

3

POSN

REG

EN

(P.814) to select the source of the current minor

loop reference. The choices are:

DISABLED

-

TORQUE

REFERENCE

(P.189) is used as the

CML

reference.

ENABLED

-

OCL

OUTPUT

(P.848) is used as the

CML

reference. This enables you

to configure the outer control loop as a type 3 position loop. This design
bypasses the speed loop. The position loop vernier signal is connected
directly to the current minor loop.

This design eliminates the need to provide a motor speed feedback device.
However, the trade-off is that it may be difficult or, in some system
configurations, impossible to achieve stable operation.

Note that

OCL

SELECT

(P.817) must be set to

POSITION

to use this feature.

.

Range:

NONE

,

CALCULATOR

,

NETW

IN

REG

1, 2, 3

P.221 =

Range:

NONE

,

CALCULATOR

,

NETW

IN

REG

1, 2, 3

P.315 =

!

ATTENTION: The J15 jumper must be set to the torque/current position
when using the WebPak 3000 drive’s type 3 position loop feature
(P.814 =

ENABLED

). Applying a drive as a direct current regulator has

safety issues that must be considered. Failure to observe this precaution
could result in severe bodily injury or loss of life.

Range:

DISABLED

,

ENABLED

P.814 =
