Configuring the Tension Outer Control Loop

12-5

12.1.4 Dynamic Gain Profiling (Variable Diameter Applications)

It is recommended that all variable diameter tension applications use dynamic gain
profiling.The gain profiler calculates the dynamic value for the

PI

block proportional

gain parameter

TEN

PI

KP

OUT

(P.879). Refer to figure A.19 in Appendix A of the

software manual (D2-3444).

þ

To configure dynamic gain profiling:

Set

TEN

PROFILER

ENABLE

(P.878) to

ENABLE

.

Set

OCL

TYPE

(P.818) to select the profiling block for cascade or parallel

operation. The choices are:

CASCADE

- The inputs to the profiling block are:

TEN

PI

PROP

GAIN

(P.841) as determined in the step response test.

NORM

FIELD

REF

(P.130)

NORM

ROLL

DIAMETER

(P.131)

SPEED

PI

KP

OUT

(P.251)

TEN

PI

LEAD

FREQ

(P.840) as determined in the step response test.

PARALLEL

- The inputs to the profiling block are:

TEN

PI

PROP

GAIN

(P.841) as determined in the step response test.

NORM

FIELD

REF

(P.130)

NORM

ROLL

DIAMETER

(P.131)

12.2 The Tension PI Output

Refer to figure A.19 in Appendix A of the software manual (D2-3444) as you configure
the tension

PI

output.

The output of the

PI

block is

TENSION

VERNIER

(P.856), which is used as a trim signal on

the speed loop when

CASCADE

is selected

or as the input to the speed loop current

limits when

PARALLEL

is selected as configured by

OCL

TYPE

(P.818).

The amount of speed loop trim is set by the

HI

and

LO

limits of the

PI

block,

TENSION

PI

LIMIT

(P.853), which would nominally be configured at 409 counts (10%). However,

product characteristics, such as modulus of elasticity, can require more or less than
10% trim.

Note that

TENSION

VERNIER

(P.856) will be a proportional or incremental trim of line

speed dependent on the configuration of

OCL

PROP

TRIM

GAIN

(P.812). Refer to section

3.3 and figure 3.1.

Range:

ENABLE

,

DISABLE

P.878 =

(1$%/(

Range:

CASCADE

,

PARALLEL

P.818 =
