13.6 Armature Voltage Feedback
Use the following parameters if necessary to configure the armature voltage feedback.
Refer to figure A.10 in the software manual (D2-3444).
13.7 Underwind Operation
Unwind and winder applications can require “over-under operation,” which is simply a
way to implement reversing operation as different products are used.
•
Digital input at terminal 6 of the Regulator board initiates underwind mode.
•
UNDERWIND
COMMAND
(P.877) indicates the state of the underwind enable command.
•
ARM
VOLTAGE
GAIN
ADJ
(P.204)
P.204 =
•
ARM
VOLTAGE
ZERO
ADJ
(P.205)
P.205 =
