9-4

WebPak 3000 DC Drive Application Workbook, Verson 1.1

The linear function is based on the equation:

Taper Percent = (Instantaneous Roll Dia. – Empty Core Dia.) / (Full Roll Dia. – Empty Core Dia.)

HYPERBOLIC

- Provides a taper profile decreasing from core to full roll based

on the equation:

Taper Percent = (1- Empty Core Dia. / Instantaneous Roll Dia.) / (1 – Empty Core Dia. / Full Roll Dia.)

TAPER

REGISTER

- Provides the capability to generate the taper curve external

to the WebPak 3000 drive and input the curve over the network interface.

TENSION

DEMAND

(P.844) is the composite outer control loop reference as modified by

the taper function.

9.2

Dancer Loading

When the outer control loop is configured for position control, the pneumatic loading of
the dancer can be electrically programmed by a voltage/current-to-pneumatic
transducer. See Appendix A in this manual for more information.

DANCER

LOADING

(P.820) is the rate-limited and scaled value of

TENSION

DEMAND

(P.844).

þ

To configure dancer loading:

Set

DANCER

ACCEL

TIME

(P.873) to specify the minimum time in which the

dancer loading output (P.820) can change from

MIN

DANCER

LOAD

(P.832) to

MAX

DANCER

LOAD

(P.831).

Set

DANCER

DECEL

TIME

(P.819) to specify the maximum time in which the

dancer loading output (P.820) can change from

MAX

DANCER

LOAD

(P.831) to

MIN

DANCER

LOAD

(P.832).

Set

MAX

DANCER

LOAD

(P.831) and

MIN

DANCER

LOAD

(P.832) to specify the

operating range of the dancer consistent with maximum and minimum tension
and with the electro-pneumatic characteristics of the transducer. Note that

MAX

DANCER

LOAD

(P.831) must be greater than

MIN

DANCER

LOAD

(P.832)

.

Set

ANLG

OUT

3

SELECT

(P.418) to

DANCER

LOADING

(P.820).

Range:

LINEAR

,

HYPERBOLIC

,

TAPER

REGISTER

P.863 =

Range: 0.1 to 60.0

SECONDS

P.873 =

SECONDS

Range: 0.1 to 60.0

SECONDS

P.819 =

SECONDS

Range: -4095 to 4095

COUNTS

P.831 =

COUNTS

Range: -4095 to 4095

COUNTS

P.832 =

COUNTS

Range:

SEE

SOFTWARE

MANUAL

(D2-3444)

P.418 =

'$1&(5

/2$',1*
