Configuring the Diameter Calculator

6-3

The remaining inputs are user configurable.

þ

To configure the diameter calculator function:

Set

WINDER

CORE

DIA

1 (P.822).

Set

WINDER

CORE

DIA

2 (P.824).

Set

WINDER

CORE

DIA

3 (P.825).

Set

EMPTY

CORE

DIAMETER

(P.830).

Set

FULL

ROLL

DIAMETER

(P.125).

Set

DIAMETER

ACCEL

RATE

(P.823).

DIAMETER

ACCEL

RATE

(P.823) sets the

maximum rate of change to ramp the diameter calculator output for a winder
application from

EMPTY

CORE

DIAMETER

(P.830) to

FULL

ROLL

DIAMETER

(P.125).

Set

DIAMETER

DECEL

RATE

(P.827).

DIAMETER

DECEL

RATE

(P.827) sets the rate

of change to ramp the diameter calculator output from

FULL

ROLL

DIAMETER

(P.125) to

EMPTY

CORE

DIAMETER

(P.830) for an unwind application.

Set

DIAMETER

CALC

ENABLE

(P.826) to

ENABLE

to activate the diameter

calculator function.

When P.826 is set to

DISABLE

, the calculated value of

NORM

ROLL

DIAMETER

(P.131)

reverts to a value determined by the parameter

DIAMETER

REGISTER

(P.874). This

supports two functions:

When the WebPak 3000 internal diameter calculator is used, the diameter register
can be used to validate the setup of the diameter calculator (see section 6.2.1).

When a network card is installed, the user has the option of providing an external
diameter calculator and use the diameter register as the diameter input over the
network.

The diameter calculator has three outputs:

ROLL

DIAMETER

(P.865) is a read-only parameter that is the value of the calculated

roll diameter in inches.

DIAMETER

ANALOG

(P.821) is the analog output of the diameter calculator scaled from

0 to 4095. At empty core, the parameter value is 0. At full roll diameter, it is 4095.

Range: 1.00 to 120.00

INCHES

P.822 =

INCHES

Range:1.00 to 120.00

INCHES

P.824 =

INCHES

Range: 1.00 to 120.00

INCHES

P.825 =

INCHES

Range: 1.00 to 30.00

INCHES

P.830 =

INCHES

Range: P.830 to 120.00

INCHES

P.125 =

INCHES

Range: 0.000 to 1.000

INCHES

/

SECOND

P.823 =

IN

/

SEC

Range: 0.000 to 1.000

INCHES

/

SECOND

P.827 =

IN

/

SEC

Range:

ENABLE

,

DISABLE

P.826 =
