86 Rockwell Automation Publication 290D-UM001A-EN-P - June 2012
Chapter 4 Bulletin 290D/291D/294D Programmable Parameters
Parameter Groups
Bulletin
290D/291D Units
Bulletin 294D Units
Common to Bulletin 290D/291D
and Bulletin 294D Units
Bulletin
290D/291D Units
Basic Status Trip Status Basic Config
1 PhaseL1Current
2 PhaseL2Current
3 PhaseL3Current
4 AverageCurrent
5%ThermalUtilized
6 StarterStatus
7 StarterCommand
8 AuxIOStatus
9 NetworkStatus
10 DLXControlStatus
11 OutputSourceV
12 SensorSourceV
13 Reserved
14 Reserved
15 Reserved 1 OutputFreq
2 CommandFreq
3 OutputCurrent
4 OutputVoltage
5 DCBusVoltage
6 StarterStatus
7 StarterCommand
8 AuxIOStatus
9 NetworkStatus
10 DLXControlStatus
11 OutputSourceV
12 SensorSourceV
13 InternalFanRPM
14 ElapsedRunTime
15 DriveTemperature 16 TripStatus
17 WarningStatus
18 TripLog0
19 TripLog1 20 TripLog2
21 TripLog3
22 TripLog4 28 FLASetting
29 OLResetLevel
30 OverloadClass
31…40 Reserved
Bulletin
290D/291D Units
Bulletin 294D Units
Trip Status
23 SnapShotL1Amps
24 SnapShotL2Amps
25 SnapShotL3Amps
26 SnapShotAvgAmps
27 SnapShot%Thermal 23 SnapShotOutFreq
24 SnapShotOutAmps
25 SnapShotOutVolts
26 SnapShotBusVolts
27 SnapShotDrvTemp
