Chapter 3
Product Commissioning
NetworkReferenceStatus
Speed reference comes from the network (not DeviceLogix)
AtReference
At commanded speed reference
DeviceLogixEnabled
DeviceLogix is enabled
KeypadAuto
HOA is in Auto mode
KeypadOff
HOA is in Off mode
KeypadHand
HOA is in Hand mode
KeypadJogging
HOA is in Jog mode
DisconnectClosed
Disconnect is closed
BrakeContactorStatus
Source brake contactor status (1 = close, 0 = open)
OutputFrequency
VFD frequency
Pt00Data
User-configured I/O status
Pt01Data
User-configured I/O status
Pt02Data
User-configured I/O status
Pt03Data
User-configured I/O status
Pt04Data
ASLT_DEMO:I.Pt04Data
Pt05Data
User-configured I/O status
Pt00DeviceOut
DeviceLogix network output status
Pt01DeviceOut
DeviceLogix network output status
Pt02DeviceOut
DeviceLogix network output status
Pt03DeviceOut
DeviceLogix network output status
Pt04DeviceOut
DeviceLogix network output status
Pt05DeviceOut
DeviceLogix network output status
Pt06DeviceOut
DeviceLogix network output status
Pt07DeviceOut
DeviceLogix network output status
Pt08DeviceOut
DeviceLogix network output status
Pt09DeviceOut
DeviceLogix network output status
Pt10DeviceOut
DeviceLogix network output status
Pt11DeviceOut
DeviceLogix network output status
Pt12DeviceOut
DeviceLogix network output status
Pt13DeviceOut
DeviceLogix network output status
Pt14DeviceOut
DeviceLogix network output status
Pt15DeviceOut
DeviceLogix network output status
Int00DeviceOut
DeviceLogix network analog output
OutputCurrent
VFD output current — Parameter 3
OutputVoltage
VFD output voltage — Parameter 4
DCBusVoltage
VFD DC bus voltage — Parameter 5
SwitchedVoltageLevel
Switched control power voltage — Parameter 11
UnswitchedVoltageLevel
Unswitched control power voltage — Parameter 12
InternalFanRPM
VFD fan speed — Parameter 13
OperatingHours
Elapse run hours — Parameter 14
DriveTemperature
VFD internal temperature — Parameter 15
TripStatus
Bit enumerate trip status — Parameter 16
WarningStatus
Bit enumerate warning status — Parameter 17
Device Input Status Tags
Tag Description/Use
