208 Rockwell Automation Publication 290D-UM001A-EN-P - June 2012
Appendix B CIP Information
Instance 3
Instance 3 is the required output (consumed) assembly.
Instance 52
Instance 52 is the required input (produced) assembly.
Instance 100
Instance 100 is the Configuration Assembly for Bulletin 290D and 291D units.
101 Config Configuration Assembly for Bulletin 294D Starters
150 Consumed Default Consumed Instance for Bulletin 290D/291D units
154 Consumed Default Consumed Instance for Inverter type units
155 Produced Default Produced Instance for Inverter units
156 Produced Exhaustive Produced Instance for Inverter type units
190 Produced 1999-ZCIO Native Format Produced Assembly
Instance Type Description
Instance 3 "ODVA Cmd"
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 — — — — — — — Run Forward
Instance 52 "ODVA Status"
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
— — — — — — RunningForward — TripPresent
Instance 100 for 290D/291D Starters
Member Index Byte Offset Name Parameter Instance
0 0 Reserved for Logix N/A
1 2 AssemblyRevision N/A
2 4 FLASetting 28
3 6 OLResetLevel 29
4 8 OverloadClass 30
5 10 ProtFltResetMode 41
6 12 ProtectFltEnable 42
7 14 WarningEnable 43
8 16 RunNetFltAction 45
9 18 RunNetFltValue 46
10 20 RunNetIdleAction 47
11 22 RunNetIdleValue 48
12 24 IOPointConfigure 49
13 26 FilterOffOn 50
