Chapter 4
Bulletin 290D/291D/294D Programmable Parameters
Zone4PtMask
Chooses consumed bytes to be placed in
Zone Data Point table
Parameter Number
117
Access Rule
SET
Data Type
DWORD
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
255
Default Value
0
Zone1PtOffset
Byte offset in Zone Data Point table to
place masked data
Parameter Number
118
Access Rule
SET
Data Type
UINT
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
7
Default Value
0
Zone2PtOffset
Byte offset in Zone Data Point table to
place masked data
Parameter Number
119
Access Rule
SET
Data Type
UINT
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
7
Default Value
0
Zone3PtOffset
Byte offset in Zone Data Point table to
place masked data
Parameter Number
120
Access Rule
SET
Data Type
UINT
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
7
Default Value
0
