Using DeviceLogix™ Appendix C
19. Go to the pull-down menu in the right corner of the toolbar and select
“Download”.
Note: Ensure that the PLC key switch is in the Program position. If in any other
position, the download will not occur and an error will be generated.
20. Press “OK” when told the download was successful.
21. Now from the same pull-down menu select “Logic Enable On.”
22. The ArmorStart is now programmed and the logic is Active.
Table 33 - DeviceLogix Input and Output Variables
Element Type Bulletin 290D Bulletin 291D Bulletin 294D
Consumed Network Data PT00DeviceIn PT00DeviceIn PT00DeviceIn
… … …
PT15DeviceIn PT15DeviceIn PT15DeviceIn
ZoneDataPt00 ZoneDataPt00 ZoneDataPt00
… … …
ZoneDataPt64 ZoneDataPt64 ZoneDataPt64
Discrete Input Points PT00 PT00 PT00
… … …
PT05 PT05 PT05
Discrete Output Points RunForward RunForward RunForward
… RunReverse RunReverse
Out00 Out00 Out00
… … …
Out05 Out05 Out05
JogForward
JogReverse
Produced Network Data Pt00DeviceOut Pt00DeviceOut Pt00DeviceOut
… … …
Pt15DeviceOut Pt15DeviceOut Pt15DeviceOut
ResetFault ResetFault ResetFault
MotionDisable MotionDisable MotionDisable
ForceSnapshot ForceSnapshot ForceSnapshot
UserDefinedFault UserDefinedFault UserDefinedFault
KeypadDisable KeypadDisable KeypadDisable
Accel2
Decel2
BrakeRelease
