8 Set NV ZIP Auto Run BOOL
Configure the ZIP producing
connection to auto-allocate on
power-up 0=disable
1=enable
9 Get* NV
Associated Connection
Instance
UINT
The instance number of the
connection object associated
with this ZIP instance. *For systems that dynamically allocate
connections, the access rule can be Set.
10 Set NV Connection Path Length UINT
Number of bytes of the
“Connection Path” attribute.
11
Set (prod)
Get (cons)
NV Connection Path EPATH
Specifies an application object
whose data is to be produced,
or is to receive consumed data. Consumed path:
21 0e 03 25 01 00 30 02
Produced path:
Produced assy path
12
Set (cons)
Get (prod)
NV Data Size UINT
The size of the data to be
produced or consumed. Consumed: 32 or 8
Procuced: size of produced assembly
13 Get* NV Connection Direction BOOL
The direction of data flow for
the connection instance
represented by this instance. 0=Producing
1=Consuming
*For systems that dynamically allocate
connections, the access rule can be Set.
14 Set* NV Data Security Disable BOOL
Enables data security
checking for the connection.
*Get access for producers.
Producers return the value 0 0=enable
1=disable
(Default = 0)
15 Set* NV Zone Analog Data Type UINT
Data type from CIP Common
Spec Table C-6.1
“Identification Codes of
Elementary Data Types”. 0xC7 = UINT
16
Set*
(Get for
producers)
NV Zone Analog Mask
STRUCT of:
USINT
Array of
BYTE
Masks individual data units of
the type defined in the “Zone
Analog Data Type” in a
consumed message for use
by in Zone Analog Data table.
Each bit in a BYTE mask
represents one unit (WORD,
REAL, etc.) of consumed data Struct of
USINT = 2
Array[2] of BYTE
Producers return USINT= 0
17
Set*
(Get for
producers)
NV Zone Analog Offset UINT
Specifies an offset into the 8-
byte Zone Point Data table to
place masked data. *Get access for producers.
Producers return UINT = 0
101 Set* NV Zone MAC ID USINT
Reflects attribute 1 for
ArmorStart LT
103 Set* NV Point Mask DWORD
Reflects attribute 3 for
ArmorStart LT This attribute matches the Array[4] structure
element in attribute 3
114 Set* NV ZoneControl BYTE
Choose consumed IO
connection properties Semantics of this bit enumerated value are the
same as params 134-137
116 Set* NV Analog Mask WORD
Reflects attribute 16 for
ArmorStart LT This attribute matches the Array[2] structure
element in attribute 16
Attribute ID Access Rule NV Name Data Type Description of Attribute Semantics of Values
