Rockwell Automation Publication 290D-UM001A-EN-P - June 2012 219
CIP Information Appendix B
Instance 8-11
Instances 8-11 are ZIP Consumers. The following instance attributes will be
supported:
The following services will be implemented for the Connection Object:
Discrete Input Point
Object CLASS CODE 0x0008
The following class attributes are currently supported for the Discrete Input
Point Object:
Six instances of the Discrete Input Point Object are supported. All instances
contain the following attributes:
Attribute ID Access Rule Name Data Type Value
1 Get State USINT 0=nonexistant
1=configuring
3=established
2 Get Instance Type USINT 1=I/O Connection
7 Get Produced Connection Size UINT 0
8 Get Consumed Connection Size UINT 8
Service Code
Implemented for:
Service Name Class Instance
0x05 No Yes Reset
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max Instance UINT 6
Attribute ID Access Rule Name Data Type Value
3 Get Value BOOL 0 = OFF, 1 = ON
4 Get Fault Status BOOL 0 = OK, 1 = Fault
115 Get/Set Force Enable BOOL 0 = Disable, 1 = Enable
116 Get/Set Force Value BOOL 0 = OFF, 1 = ON
