Chapter 4
Bulletin 290D/291D/294D Programmable Parameters
Zone4AnalogMask
Byte offset in Zone Data Point table to
place masked data
Parameter Number
125
Access Rule
SET
Data Type
WORD
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
255
Default Value
0
Zone1AnOffset
Word offset in Analog Zone Data to place
masked analog data
Parameter Number
126
Access Rule
SET
Data Type
UINT
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
7
Default Value
0
Zone2AnOffset
Word offset in Analog Zone Data to place
masked analog data
Parameter Number
127
Access Rule
SET
Data Type
UINT
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
7
Default Value
0
Zone3AnOffset
Word offset in Analog Zone Data to place
masked analog data
Parameter Number
128
Access Rule
SET
Data Type
UINT
Group
ZIP
Units
–
Minimum Value
0
Maximum Value
7
Default Value
0
