AT&T System 25 - Manual (Page 381)

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTlON POSSIBLE SOLUTION
1 0 1 7 : inappropriate request Cap already installed
system already has Direct
C A P
ACTION = 1 (Cap)
Go to MENU 8 (Searches)
ACTION = 1 DATA = 18
ACTION = 2 DATA = 309 or 310
ACTION = 3 DATA = 0
1 0 1 8 : inappropriate request Must remove secondary CAP before
must remove secondary attempting to remove the first CAP.
CAP first
1 0 1 9 : incorrect action number Check if the ACTION value taken is
does not exist or used legal.
improperly
1 0 2 0 : inappropriate request Trying to administer features to a
primary or secondary secondary CAP that does not exist.
CAP does not exist
1021: at installed max At the maximum number of stations
-200 stations allowed by the system.
1022: at installed max At the maximum number of trunks
-104 trunk allowed by the system.
1023: button function code Button station out of range for
out of range terminal type code. Check station
does not exist or used for button range. (invalid button
improperly function code)
1 0 2 4 : at installed max At system maximum of 300 FPDCs.
-300 FPDCs
1025: at installed max -199 At system maximum of 199 EMT
EMT sets s e t s .
1026: at installation max Maximum of 111 ATL sets, 2 of
-96 ATL set which have to be CAPS
1027: at installed max At system maximum of 104
-104 trunk ground-start trunks.
1028: at installed max At system maximum of 104 loop-
-104 trunk start trunks.
1029: at installed max At system maximum of 104 DID
-104 trunk t r u n k s .
1 0 3 0 : at installed max At system maximum of 32 TIE
-32 Tie trunk trunks.
F-3
