APPENDIX E: Administration Codes and Data
Table E-AG. RS232 Port Administration (Menu=10)
In response to "RS232=", enter the RS232 connector (1-5*) to be
administered.
ACTION DESCRIPTION DATA
1 Reassign RS232 connector capability [0 to disconnect
port or see
footnote † for
options and
defaults]
2 For Ports 1-4 ONLY*: Change the [0-2;0]
RETURN delay
3 For Ports 1-4 ONLY*: Change the [300, 1200,
baud rate 4800, 9600
See footnote †
for defaults]
● Ports 1-4 are the RS232 connectors off the Call Processor. Port 5 is a special modem port
accessed through the switch fabric for RIMS.
† The default for each Target connector is as follows:
TARGET DEFAULT DATA (= Capability) DEFAULT BAUD RATE
1 1 (= Administration) 1200, 300 (auto-baud)
2 2 (=SMDR) 1200
3 3 (= Save/Restore Tape) 1200
4 Reserved 9600, 1200 (auto-baud)
5 RIMS 1200
E-55
