INSTALLATION
73001H Series Voice Terminals
See Figure 2-51.
1.
2.
3.
4.
5.
6.
7.
Unpack each terminal and examine it for damage.
At the workstation, use a D8W-87 modular cord to connect the NAU
jack on the KS-23475, L1 Adapter to the OUT jack on the NAU.
Using a D8W-87 modular cord, connect the PHONE jack on the KS- ,
23475, L1 Adapter to the voice terminal.
Connect the POWER plug on the KS-23475, L1 Adapter to the KS-
2 2 9 1 1 P o w e r U n i t .
Connect the plug on the KS-23475, L1 Adapter’s modular cord to the
modular wall jack.
Locate the workstation appearance at the SIP and disconnect the
octopus cable. Install a WP90581, L1 Y Adapter and connect the
octopus cable plug to the VOICE jack.
Using a D8W-87 modular cord, connect the DATA jack on the Y
adapter to the STARLAN NETWORK NEU IN jack.
