INSTALLATION

S Y S T E M 2 5

C A B I N E T

P A R T O F

2 5 P A I R C A B L E

P A R T O F

6 6 - B L O C K

A

W 1

C 5

T N 7 6 3

B 1

<

P A G I N G O R

DICTATION

S Y S T E M

LEGEND :

TN763– AUXILIARY TRUNK CP
A – SINGLE-ENDED 25 PAIR CONNECTOR CABLE (A25D)

B1 - T Y P I C A L -

1 0 3 A C O N N E C T I N G B L O C K

C5 -MODULAR CORD (D4BU-87)
W1 - I N S I D E W I R I N G C A B L E ( 4 - P A I R )

NOTE :

Figure

APPARATUS CODE D-181523 INCLUDES

66E3-25 BLOCK CONNECTOR AND CABLE

B 2 5 A 1 5 / D E .

2-55.

Paging System Connection to TN763 Circuit Pack

2-123
