Section II: Menu Interface
54
3. Return to the Module Status Menu.
Fan Module
Settings
To configure the settings of the fan modules (FAN A or FAN B), perform
the following procedure:
1. From the Module Status Menu, use the arrow keys on the keyboard to
select the fan module whose settings you wish to configure.
2. Press the Enter key.
The Module Configuration menu for a fan module is displayed in
Figure 25.
Figure 25 Example of Module Configuration Menu - FAN Module
The fields in the Module Configuration menu for the fan module
are defined in the table below:
3. Return to the Module Status Menu.
Module name Specifies the name for the power supply module. The
module name can be up to 20 alphanumeric characters
in length.
Parameter Description
Parameter Description
Status Displays the status of the fan module. The
available settings are:
• Good
• Failed
Speed Displays the speed of the fan module.
Module name Specifies the name for the power supply
module. The module name can be up to 20
alphanumeric characters in length.
Module 14 - AT-FAN01 1
Status Good
Speed +3552rpm
Module name
Return to Module Status Menu...
