Section II: Menu Interface
38
❑ To view the port statistics, select Individual channel overview. The
Individual channel overview menu is displayed in Figure 15.
Figure 15 Individual Channel Overview Menu
❑ If Run-Length-Limit (RLL) errors occurred in one of the channels,
you can view them from the RLL Error (TX) Graph. The RLL error
graphs for the transmit (TX) and the receive (RX) ports are
displayed in two separate menus.
Figure 16 Example of an RLL Error (TX) Graph Menu
❑ To reset all the channel statistics counters on the entire system to
zero (0), select Zero all statistics counters on the entire system.
Individual channel overview
1: CH 1
2: CH 2
3: CH 3
4: CH 4
5: CH 5
6: CH 6
7: CH 7
8: CH 8
Return to Statistics Menu...
RLL Error (RX) Graph
CH 1: 0 |
CH 2: 5 |
CH 3: 0 |
CH 4: 0 |
CH 5: 0 |
CH 6: 198 |
CH 7: 0 |
CH 8: 0 |
----------------------------------
Zero all statistics counters on the entire
system
Return to Statistics Menu...
