Section II: Menu Interface
44
Displaying Module Status
The Module Status Menu displays the operating status of the following
modules:
❑ GBIC ports (CH1 to CH8)
❑ Multiplexing ports - WEST (OPT A) and EAST (OPT B)
❑ Optional management module ports (WDM02)
❑ Standard power supply (RPS A)
❑ Optional redundant power supply (RPS B)
❑ Fan modules (FAN A & FAN B)
To display the status of the ports and the modules in the multiplexer,
perform the following procedure:
1. From the Main Menu, select Module status and configuration.
The Module Status Menu is displayed in Figure 20.
Figure 20 Module Status Menu
The fields in the Module Status Menu are defined in the Table 2.
Module Status Menu
Module
Tx/Status
Rx
1. GBIC
Online
Online
2. GBIC
Online
Online
3. GBIC
Online
Online
4. GBIC
Online
Online
5. GBIC
Online
Online
6. GBIC
Online
Online
7. GBIC
Online
Online
8. GBIC
Online
Online
9. OPT A
Online
Online
10.OPT B
Online
Online
12.AT-WDM02
Online
13.AT-WRPS A
On
14.AT-WRPS B
On
15.AT-WFAN01 1
Good
16.AT-WFAN01 2
Good
>
Enable missing link
Disable missing link
Return to Main Menu...
