Section II: Menu Interface
52
3. Return to the Module Status Menu.
Management
Module Settings
To configure the settings of the AT-WDM02 Management Module,
perform the following procedure:
1. From the Module Status Menu, use the arrow keys on the keyboard to
select the management module.
2. Press the Enter key.
The Module Configuration menu for a management module is
displayed in Figure 23.
Figure 23 Example of Module Configuration Menu -
Management Module
Taken together, these two port shutdown selections
give you complete control over a GBIC port’s ability to
send traffic, both to its end node and to the
multiplexing port. If you want to shutdown a GBIC
port completely so that it will not send traffic in either
direction, you must use both shutdown selections.
Link Test Disable
OPT X
Link Test Enable
OPT X
Disables or enables the Link Test feature for the
selected multiplexing port. For instructions on how to
perform a Link Test, refer to Enabling or Disabling
Link Test on page 58.
Parameter Description
Module 11 - AT-WDM02
Port Link
Tx Online
Module name
Return to Module Status Menu...
