To view the RLL Errors that have occurred in both the transmit (TX) and
the receive (RX) ports of a channel, select the channel. The RLL Error
Graph Menu for the selected channel is displayed. An example is shown
in Figure 17.
Figure 17 Example of Individual Channel Graph Menu
❑ To reset the channel statistics counters only on a selected channel
to zero (0), select Zero this module statistics counters on the entire
system.
❑ To reset all the channel statistics counters on the entire system to
zero (0), select Zero all statistics counters on the entire system.
CH 2 Graph
RLL Error (TX): 120 |
RLL Error (RX): 5 |
---------------------------
Zero this module statistics counters on the
entire system
Zero all statistics counters on the entire
system
Return to Individual channel overview...
