Section II: Menu Interface

50

The Module Configuration menu for a multiplexing port is
displayed in Figure 22.

Figure 22 Example of Module Configuration Menu - Multiplexing Port

The fields in the Module Configuration menu for the multiplexing
ports are defined in the table below:

Parameter

Description

Port - Link

Indicates the status of the multiplexing port. Refer to
Table 2 on page 45 for descriptions of the possible
statuses.

Channel (1, 2, 3, 4)
or
Channel (5, 6, 7, 8)

Displays the status of the GBIC ports handled by the
WEST (OPT A) or the EAST (OPT B) multiplexing port.

Channels (1 to 4) are displayed when the WEST

(OPT A) multiplexing port is selected.

Channels (5 to 8) are displayed when the EAST

(OPT B) multiplexing port is selected.

The statuses are:

Port Active - The GBIC port can send traffic through

the multiplexing port.

Port Shutdown - The GBIC port cannot send traffic

through the multiplexing port.

Module 9 - OPT A

Port

Link

Tx

Online

Rx

Online

Channel

Active/Shutdown

1 :

Active

2 :

Active

3 :

Active

4 :

Active

Module name

CH 1
CH 2
CH 3
CH 4

> Link Test Disable OPT A

Link Test Enable OPT A

Return to Module Status Menu...
