Icons

The following icons may appear in the view:

Description

Icon

Storage system is normal

Storage system is initializing or in an unknown state

Storage system is disabled, degraded, or unmanaged

Storage system is failed or there is a bad connection to the storage manager

DR group is normal

DR group is disabled, degraded, unknown, copying, constructing, or deleting

DR group is failed

Remote replication is in a steady state

Remote replication is not in a steady state

Virtual disk is normal

Virtual disk is in an unknown state

Virtual disk is degraded, disabled, deleting, copying, or constructing

Virtual disk is failed

More help

Overview. See

About topology views

.

Tips. See topology view

Tips

.

Filters. See

Filters for views

.

Host volumes topology view

Description

The host volumes topology view shows logical relationships among enabled hosts, their host
volumes, and the underlying virtual disks in the host volumes. The default layout is organized in
centric circles. Enabled hosts, host volumes, and virtual disks appear in the inner, middle, and
outer circles, respectively.

Topology views

57
