HP P6000 Continuous Access Software - Manual (Page 216)

Template options
•
Number of components to mount. Adds commands for each component.
•
Suspend source before replication. Adds launch commands for interacting with an enabled
host, for example to suspend and resume host application I/O.
•
Launch backup after replication. Adds a launch command for interacting with an enabled
host, for example, to start a tape backup.
•
Use snapclone instead of snapshot. Generates a template that uses snapclone replication.
•
Include e-mail notification. Adds a command for e-mail notification of the job instance status.
See
SetNotificationPolicy .
Considerations
•
Tru64 UNIX. When replicating AdvFS volumes that have heavy I/O, select the option Suspend
source before replication. See
Suspending I/O before replicating AdvFS volumes .
Example
This template was generated to locally replicate and mount one host volume. No other template
options were selected.
Task Line
// Replicate a host volume, and mount slices/partitions/LVs to a host. 1
// 2
// Assign some variables that will be used in this job. 3
$mount_host = SetVariable(%mount_host%) 4
$source_host = SetVariable(%source_host%) 5
$source_hostvol_unc1 = SetVariable(%source_hostvol_unc1%) 6
// 7
// Validate that resources are as expected. 8
ValidateHost ($mount_host) 9
ValidateHostVolume ($source_hostvol_unc1) 10
ValidateSnapshotHostVolume ($source_hostvol_unc1) 11
// 12
$Rep1 = SnapshotHostVolume ($source_hostvol_unc1, FULLY_ALLOCATED, SAME, WAIT) onerror pauseat E1: 13
// 14
// Mount the replicated volume(s) on a host. 15
PresentStorageVolumes ($Rep1, $mount_host) onerror pauseat E2: 16
DiscoverDiskDevices ($mount_host, $Rep1) onerror continue 17
$HV1 = CreateHostVolumeFromDiskDevices ($source_hostvol_unc1, $Rep1, $mount_host) onerror pauseat E2: 18
$MP1 = MountHostVolume ($HV1, %mount_point1%) onerror pauseat E3: 19
// 20
// Wait for user to initiate rollback. 21
Pause () 22
216 Jobs
